Word Clock Input Connector
This 75 ohm BNC socket is used for the word clock input, and has the following connections;
Inner: Signal.
Outer: Screen.
AES/EBU Sync Input Connector
This XLR 3 pin socket is used for AES/EBU Sync Input, and has the following connections;
Pin 1: Screen.
Pin 2: Phase.
Pin 3: Non-phase.
Channel Options, Jumper Settings and Presets
The PGM digital stereo output channel can be congured in a number of dierent ways
depending on the jumper options set on the board. The on board processors software
is congured by jumpers J3 to J9 and channel identifying links. The PGM digital output
channel is identied by having links LK42 and LK45 tted. The PGM digital output channel
with Fader is identied by having links LK42, LK45 and LK46 tted.
The standard options available are;
t $MFBOGFFENJYCVTUFSNJOBUJPO
t 4FMFDUNPEFBOETBNQMFSBUF
t 4FMFDUDIBOOFMTUBUVTCJUT
t 4FMFDU"&4&#6PS41%*'PVUQVU
t 4FMFDU"&4&#6PS41%*'TZODJOQVU
S2ODPF/S2ODP DIGITAL OUTPUT
PGM CHANNEL WITH & WITHOUT
MASTER FADER VERSION 2
S2ODPF/S2ODP DIGITAL OUTPUT PGM CHANNEL
WITH & WITHOUT MASTER FADER VERSION 2
