Sonifex S2 - Channel Options, Jumper Settings and Presets

S2 User Handbook
85
12
S2-CSMM STEREO MIX MINUS
CHANNEL WITH EQ
S2-CSMM STEREO MIX MINUS CHANNEL WITH EQ
The connector pin-out is as follows;
Pin 1: Opto isolated Line input start NPN collector.
Pin 2: Common NPN emitter for Line 1 start and stop.
Pin 3: Opto isolated Line input stop NPN collector.
Pin 4: No connection.
Pin 5: No connection.
Pin 6: No connection.
Pin 7: 0V logic.
Pin 8: General purpose I/O 1.
Pin 9: General purpose I/O 2.
Line Left Input Connector
This XLR 3 pin socket is used for the left channel input, and has the following connections;
Pin 1: Screen.
Pin 2: Phase.
Pin 3: Non-phase.
Line Right Input Connector
This XLR 3 pin socket is used for the right channel input, and has the following connections;
Pin 1: Screen.
Pin 2: Phase.
Pin 3: Non-phase.
Channel Options, Jumper Settings and Presets
The stereo mix-minus channel with EQ can be congured in a number of dierent ways
depending on the jumper options set on the board. The on-board processor’s software is
congured by jumpers J1 to J5 and channel identifying links. The stereo mix-minus channel
is identied by having links LK8 and LK11 tted. Other, customer specic, options can be
programmed into the software by special order. Special logic options will be identied by
having links LK9 and LK10 tted.
The standard options available are;
t 4FMFDUNPNFOUBSZPSMBUDIFETUBSUGPSUIF*OQVU
t &OBCMFDPOUJOVPVTNPNFOUBSZTUBSUGSPN0/CVUUPO
t &OBCMFPSEJTBCMF$VF1'-DBODFMGSPNGBEFS
t 4FMFDUUJNFSPQUJPO
t $MFBOGFFEPVUQVUTFMFDUJPO
t Bal/Pan Control Setup
