Sonifex S2 - Channel Options, Jumper Settings and Presets

78
S2 User Handbook
11
S2CT TELCO CHANNEL WITH EQ
S2CT TELCO CHANNEL WITH EQ
Pin 1: Screen.
Pin 2: Phase.
Pin 3: Non-phase.
Channel Options, Jumper Settings and Presets
The telco channel with EQ can be congured in a number of dierent ways depending
on the jumper options set on the board. The on-board processor’s software is congured
by jumpers J1, J4 and channel identifying links. The telco channel is identied by having
links LK21 and LK22 tted. Other, customer specic, options can be programmed into the
software by special order. Special logic options will be identied by having links LK23 and
LK24 tted.
The standard options available are;
t 4FMFDUNPNFOUBSZPSMBUDIFE)ZCSJEIPME
t &OBCMFPSEJTBCMF$VF1'-DBODFMGSPNGBEFS
t $MFBOGFFETFMFDUJPOKVNQFST++NVTUCFTFUUIFTBNFGPSBUFMDPNPEVMF
t 4FMFDUUJNFSPQUJPO
t .VUF$MFBOGFFEPO5BMLCBDLFOBCMF
Summary of Jumper Settings for the Telco Channel With EQ
Jumper Set over Pins Eect
J1
1 & 2
None
Latching contact for telephone hybrid hold.
Momentary contact for telephone hybrid hold.
J2
1&2
None
Mute C/F on Talkback enable.
Talkback mixed onto C/F output on Talkback enable.
J3 Not Fitted
J4
1 & 2
None
Fader up signal cancels previously selected CUE/PFL.
Normal Cue/PFL function.
J5 Not Fitted
J6 Not Fitted
J7 Not Fitted
J8 Not Fitted
J9 Not Fitted
J10 Not Fitted
J11
1 & 2
2 & 3
Set-up for cleanfeed bus 1.
Set-up for cleanfeed bus 2.
J12
1 & 2
2 & 3
Set-up for cleanfeed bus 1.
Set-up for cleanfeed bus 2.
J13 Not Fitted
J14 Not Fitted
J15 Not Fitted
Note: Options in bold are set as default when shipped.
