S2 User Handbook
Summary of Jumper Settings for the PGM Digital Output Channel
Jumper Set over Pins Eect
J1
1 & 2
None
Cleanfeed 1 terminated.
Cleanfeed 1 active.
J2
1 & 2
None
Cleanfeed 2 terminated.
Cleanfeed 2 active.
J3-J6
See table (page 103) Synchronisation Mode & Sample Rate
Selection.
J7-J8 Reserved.
J9 See table (page 103) Channel Status Bits Selection.
J10
1 & 2
2 & 3
AES/EBU sync input selected.
S/PDIF sync input selected.
J11 1 & 2 AES/EBU sync input selected.
2 & 3 S/PDIF sync input selected.
J12 1 & 2 S/PDIF output selected.
2 & 3 AES/EBU output selected.
J13
1&2
None
Reserved.
Reserved.
Note: Options in bold are set as default when shipped.
S2ODPF/S2ODP DIGITAL OUTPUT
PGM CHANNEL WITH & WITHOUT
MASTER FADER VERSION2
S2ODPF/S2ODP DIGITAL OUTPUT PGM CHANNEL
WITH & WITHOUT MASTER FADER VERSION 2
