S2 User Handbook
39
S2CMM MIC/MIC CHANNEL WITH EQ
S2CMM MIC/MIC CHANNEL WITH EQ
6
Summary of Jumper Settings for the Mic/Mic Channel With EQ
Jumper Set over Pins Eect
J1
1 & 2
None
Latching contact for Mic 1 cue light.
Momentary contact for Mic 1 cue light.
J2
1 & 2
None
Latching contact for Mic 2 cue light.
Momentary contact for Mic 2 cue light.
J3
1 & 2
None
Continuous momentary start from ON button,
see following description.
Normal start function.
J4
1 & 2
None
Fader up signal cancels previously selected Cue/PFL.
Normal Cue/PFL function.
J5 Not Fitted
J6
1 & 2
2 & 3
Phantom power to Microphone 1.
Normal operation.
J7
1 & 2
None
Full LF response on Microphone 1 input.
LF roll o.
J8
1 & 2
2 & 3
Phantom power to Microphone 2.
Normal operation.
J9
1 & 2
None
Full LF response on Microphone 2 input.
LF roll o.
J10
1 & 2
None
Insert point enabled (Insert in).
Insert out only.
J11 Not Fitted
J12 Not Fitted
J13
1 & 2
2 & 3
None
Control room monitor mute from Microphone 1 input.
Studio monitor mute from Microphone 1 input.
No mute function.
J14 Not Fitted
J15
1 & 2
2 & 3
None
Control room monitor mute from Microphone 2 input.
Studio monitor mute from Microphone 2 input.
No mute function.
J16
1&2
2&3
None
MIC1 is selected as Talkback input
MIC2 is selected as Talkback input
No Talkback input
Note: Options in bold are set as default when shipped.
