S2 User Handbook
METERBRIDGE MODULES
METERBRIDGE MODULES
20
The connector pin-out is as follows;
Pin 1: +15V.
Pin 2: Oer switch.
Pin 3: Accept switch.
Pin 4: Delay switch.
Pin 5: Dump switch.
Pin 6: Talkback 1 switch.
Pin 7: Talkback 2 switch.
Pin 8: Talkback 3 switch.
Pin 9: Talkback 4 switch.
Pin 10: Talkback all switch.
Pin 11: Ground.
Pin 12: Talkback out.
Pin 13: Talkback control out.
Pin 14: Ground.
Pin 15: Oer indicator.
Pin 16: Accept indicator.
Pin 17: Delay indicator.
Pin 18: Dump indicator.
Pin 19: Talkback 1 indicator.
Pin 20: Talkback 2 indicator.
Pin 21: Talkback 3 indicator.
Pin 22: Talkback 4 indicator.
Pin 23: Talkback in.
Pin 24: Ground.
Pin 25: Ground.
Mixer Talkback Connector
This 9 pin D type plug is used for connecting the Talkback module to the Control Room
Monitor channel. The connection cable is supplied with the Talkback module, which plugs
into the S2-MTBS via the mixer meterbridge housing, and down into the two talkback jack
sockets on the rear of the Control Room channel.
The connector pin-out is as follows;
Pin 1: Talkback in phase (to mixer).
Pin 2: Talkback control.
Pin 3: No connection.
Pin 4: Talkback out phase (from mixer).
Pin 5: Ground.
Pin 6: Talkback in non-phase (to mixer).
Pin 7: No connection.
Pin 8: Talkback out non-phase (from mixer).
Pin 9: No connection.
