S2 User Handbook
149
METERBRIDGE MODULES
METERBRIDGE MODULES
20
RS232 Port
The RS232 communications port is fully congurable, with separate options for data bits,
stop bits, and baud rate, which can all be set independently of each other.
Option
Number
Sub Option
Number
Description
1 - RS232 Data Bits
0 7 data bits
1 8 data bits
2 - RS232 Stop Bits
0 1 stop bit
1 2 stop bits
3 - RS232 Parity
0 None
1 Even parity
2 Odd parity
4 - RS232 Baud Rate
0 9600 baud
1 19200 baud
2 38400 baud
3 57600 baud
4 115200 baud
5 - RS232 Output
0 Disable
1 Enable
RS232 Output Format
A time code string can be output from the timer module for use in synchronising other
devices to the module.
“dd/mm/yy,hh:mm:ss,A,B,C,D,hh:mm:ss.tt,hh:mm:ss.tt,hh:mm:ss.tt\r\n”
DATE,TIME,[3 MODE CH],TIMER_1,TIMER_2,MIC_TIMER.
A = Date string format. (See option no. 6)
B = Time code synchronisation source (see option no. 0)
C = Indication of lock to source 0 = not locked, 1 = signal/not locked, 2 = locked.
Also note that source number 0 (internal RTC) implies “not locked”.
D = Indication of presence of timecode signal 0 = No signal, 1 = Signal present.
\n = New Line.
\r = Carriage return.
RS232 Input Format
“dd/mm/yy,hh:mm:ss\r\n”
DATE,TIME
(Date format is dependent on setting of option no. 6.)
