S2 User Handbook
151
METERBRIDGE MODULES
METERBRIDGE MODULES
20
Option
Number
Sub Option
Number
Description
13 - Freeze Time
0 On second event freeze display for 1 second
1 On second event freeze display for 2 seconds
2 On second event freeze display for 3 seconds
3 On second event freeze display for 4 seconds
4 On second event freeze display for 5 seconds
14 - Time Setting
0 Disallow while locked to time code source
1 Allow while locked to time code source
15 - SMPTE/EBU Timecode settings
0 Ignore date
1 Date Format 1
2 Date Format 2
3 Date Format 3
SMPTE/EBU Timecode Settings
Setting sub option 0 in option 15 will allow the unit to ignore any date information within
the timecode stream. The date will be displayed as “––.––.––”.
The remaining sub options allow the unit to handle various date formats within the
timecode. The formats are dened as follows:
Date Format 1 Date Format 2 Date Format 3
Bits 12 to 15 Days Units Bits 20 to 23 Years Units Bits 20 to 23 Years Units
Bits 20 to 23 Months Units Bits 28 to 31 Years Tens Bits 28 to 31 Years Tens
Bits 28 to 29 Days Tens Bits 36 to 39 Months Units Bits 36 to 39 Days Units
Bits 30 Month Tens Bits 44 to 45 Month Tens Bits 44 to 45 Days Tens
Bits 44 to 47 Years Units Bits 52 to 55 Days Units Bits 52 to 55 Months Units
Bits 60 to 63 Years Tens Bits 60 to 62 Days Tens Bits 60 to 62 Month Tens
