S2 User Handbook
35
MIC/LINE
Mode 1 : Normal. Can be selected as normal.
Mode 2 : Always Line. Line is permanently selected.
Mode 3 : Always MIC. MIC is permanently selected.
EQ
Mode 1 : Normal. Equalization can be enabled or disabled as normal.
Mode 2 : Always enabled. Equalization controls are permanently enabled.
Mode 3 : Always disabled. Equalization controls are permanently disabled.
Cue/PFL
Mode 1 : Normal. Cue/PFL is selected as normal, with both a momentary or
latched operation.
Mode 2 : Latched. Cue/PFL is selected as normal, but will only work with a
latched operation.
Mode 3 : Momentary. Cue/PFL is selected as normal, but will only work with a
momentary operation.
ON
Mode 1 : Normal.
Mode 2 : Always on. The channel cannot be turned o.
Mode 3 : Always on and no LED indication. The channel cannot be turned o and the
On button LEDs are never active.
S2CML MIC/LINE CHANNEL WITH EQ
S2CML MIC/LINE CHANNEL WITH EQ
5
