S2 User Handbook
e
CONTENTS
CONTENTS
16 S2-ODAF/S2-ODA Digital Output AUD Channel With & Without
Master Fader (Version 1) 108
Panel Controls 108
Rear Panel 109
Channel Options, Jumper Settings and Presets 110
17 S2-ODAF/S2-ODA Digital Output AUD Channel With & Without
Master Fader (Version 2) 115
Panel Controls 115
Rear Panel 115
Channel Options, Jumper Settings and Presets 117
18 S2-OMC Control Room Monitor Channel 122
Panel Controls 122
Rear Panel 123
Channel Options and Jumper Settings 124
19 S2-OMS Studio Monitor Channel 128
Panel Controls 128
Rear Panel 129
Channel Options and Jumper Settings 130
20 Meterbridge Modules 134
Meterbridge Module Types 134
Meterbridge Distribution Board 135
S2-MB1-5 Meterbridge Blanking Plates 136
S2-ML Meterbridge Loudspeaker Monitor Panel 136
S2-MVU Meterbridge VU Meter Panel, S2-MPPM PPM Meter Panel
& S2-ML53 LED Meter Panel 137
S2-MPH Meterbridge Phase Meter Panel 139
S2-MTB6 Meterbridge 6 Way Talkback Panel 140
S2-MTBS Meterbridge Station Master Talkback Panel 141
S2-MSB1 Meterbridge Switch Panel With 1 Button
145
S2-MSB3 Meterbridge Switch Panel With 3 Buttons 145
S2-MT Meterbridge Timer Panel 146
Overview 146
Panel Controls 146
Rear Panel 147
Conguring The Timer 147
21 Technical Specications 152
S2 Mixer Weights and Boxed Dimensions 154
Glossary 155
