S2 User Handbook

S2CSGE/S2CSG STEREO LINE AND

GRAM CHANNEL WITH & WITHOUT EQ

S2CSGE/S2CSG STEREO LINE AND

GRAM CHANNEL WITH & WITHOUT EQ

functionality. To make use of these modes, you must enter a setup mode which is exactly

the same for every module. It is only necessary to perform this procedure once.

To enter the setup mode, hold down the PGM and AUD buttons together for 5 seconds.

After which all the buttons will start a recurring ashing sequence, at this point it is ok to

release the PGM and AUD buttons. This sequence indicates the mode which each button is

currently set to. One ash equals mode one, two ashes equals mode two etc. To change the

mode for a particular button simply press it once and watch the number of ashes increase.

Once the maximum mode number has been reached it will simply wrap around to mode

one and continue as before. To exit this setup procedure press and hold both the PGM and

AUD buttons as before for 2 seconds and the module will start operating

as normal.

Each button and their corresponding modes are listed below.

PGM

Mode 1 : Normal. The program bus can be selected as normal.

Mode 2 : Always on. The program bus is permanently selected.

Mode 3 : Always o. The program bus is permanently deselected.

AUD

Mode 1 : Normal. The audition bus can be selected as normal.

Mode 2 : Always on. The audition bus is permanently selected.

Mode 3 : Always o. The audition bus is permanently deselected.

INP1/INP2

Mode 1 : Normal. Can be selected as normal.

Mode 2 : Always INP2. INP2 is permanently selected.

Mode 3 : Always INP1. INP1 is permanently selected.

EQ (S2-CSGE only)

Mode 1 : Normal. Equalization can be enabled or disabled as normal.

Mode 2 : Always enabled. Equalization controls are permanently enabled.

Mode 3 : Always disabled. Equalization controls are permanently disabled.

Cue/PFL

Mode 1 : Normal. Cue/PFL is selected as normal, with both a momentary or latched

operation.

Mode 2 : Latched. Cue/PFL is selected as normal, but will only work with a

latched operation.

Mode 3 : Momentary. Cue/PFL is selected as normal, but will only work with a

momentary operation.
