S2 User Handbook
65
Remote for Digital Input 1
The remote output for Input 1 can be used for a start and stop function wired to other
studio equipment such as CD or MD players. The default setting for J1 is none (not tted),
which produces a momentary remote contact. If your equipment requires a latching contact
for remote start then a jumper should be placed over pins 1 & 2 of J1. The remote stop for
Input 1 is always momentary.
Remote for Digital Input 2
The remote output for Input 2 can be used for a start and stop function wired to other
studio equipment such as CD or MD players. The default setting for J2 is none (not tted),
which produces a momentary remote contact. If your equipment requires a latching contact
for remote start then a jumper should be placed over pins 1 & 2 of J2. The remote stop for
Input 2 is always momentary.
Continuous Momentary Start
The continuous momentary start function can be used for equipment that only ever
requires a remote start but not a stop. Placing a jumper over J3 pins 1 & 2 enables the
function. When enabled the operation of the ON button is changed to a continuous start
button. With the fader down, the button shows red. With the fader up, the button shows
green and each press of the ON button will trigger a momentary start from the remote
contacts. The default setting for J3 is none (not tted). It is not possible to congure a
latching remote start output when the continuous momentary start option has been
selected.
CUE/PFL Cancel
The CUE/PFL function is normally an alternate action. Press the button to select and press
again to de-select. However it may be desirable to have the fader up signal cancel a CUE/
PFL selection. Placing a jumper over J4 pins 1 & 2 will enable a previously selected CUE/PFL
function to be cancelled when the fader is up and the channel is ON. The default setting is
none (not tted).
De-emphasis
Placing a jumper over pins 1 & 2 of J3 will decode 50/15μs emphasis when indicated by
certain channel status bits in the incoming digital audio data.
Disabling PFL When no Input is Detected
When J11 is tted, if a digital input is not detected on the selected input, then PFL is
disabled/muted.
Timer Auto Start
The dual timer in the meterbridge can be set to start automatically from a fader open/
channel On signal. Jumper J6 determines which timer is set to auto-start. A jumper over pins
1 & 2 will start Timer 1, shifting the jumper to pins 2 & 3 will start Timer 2. The default setting
of J6 is none (not tted).
Jumpers J7 to J10 are not tted to this channel.
S2CDSE/S2CDS DIGITAL DUAL
STEREO LINE CHANNEL WITH &
WITHOUT EQ
9
S2CDSE/S2CDS DIGITAL DUAL STEREO LINE CHANNEL WITH & WITHOUT EQ
