S2 User Handbook
67
General Purpose I/O Function Options
GPIO Function
ON Button
Cue/PFL
Button
AUD
Button
Input/Output
Latching/
Momentary
Active Low/
Active High
I L AL OFF OFF OFF
I M AL ON OFF OFF
I L AH OFF ON OFF
I M AH ON ON OFF
O L AL OFF OFF ON
O M AL ON OFF ON
O L AH OFF ON ON
O M AH ON ON ON
t /PXTFMFDU(1*0TBDUJPOVTJOHUIF1(.CVUUPOBTCFGPSF
General Purpose I/O Action Options
The functions available are dependent on whether the remote is set as an input or an
output. The two tables below describe the dierent functions available.
Input Functions
GPIO
Action
Description ON
Button
Cue/PFL
Button
AUD
Button
None - OFF OFF OFF
Channel
ON
The remote pin replicates the ON
button in the module. Activating this
control will turn the channel on or o.
ON OFF OFF
Red ON
Indicator
The remote pin activates the Red LED
in the ON Button. The ON button mode
must be set to mode 5 or 6 when using
this action.
OFF ON OFF
Green ON
Indicator
The remote pin activates the Green
LED in the ON Button. The ON button
mode must be set to mode 5 or 6 when
using this action.
ON ON OFF
Fader On
The remote pin controls the fader open
function. When active, the fader is fully
open.
OFF OFF ON
Output Functions
GPIO
Action
Description ON
Button
Cue/PFL
Button
AUD
Button
None - OFF OFF OFF
Channel
ON
The remote pin goes active when the
channel is LIVE.
ON OFF OFF
S2CDSE/S2CDS DIGITAL DUAL
STEREO LINE CHANNEL WITH &
WITHOUT EQ
