S2 User Handbook
69
EQ (S2-CDSE only)
Mode 1 : Normal. Equalization can be enabled or disabled as normal.
Mode 2 : Always enabled. Equalization controls are permanently enabled.
Mode 3 : Always disabled. Equalization controls are permanently disabled.
Cue/PFL
Mode 1 : Normal. Cue/PFL is selected as normal, with both a momentary or latched
operation.
Mode 2 : Latched. Cue/PFL is selected as normal, but will only work with a
latched operation.
Mode 3 : Momentary. Cue/PFL is selected as normal, but will only work with a momentary
operation.
Mode 4 : Normal with remotes. Cue/PFL is selected as normal, with both a momentary or
latched operation and will also activate the remotes if the channel is not live.
Mode 5 : Latched with remotes. Cue/PFL is selected as normal, but with only a latched
operation and will also activate the remotes if the channel is not live.
Mode 6 : Momentary with remotes. Cue/PFL is selected as normal, but with only a
momentary operation and will also activate the remotes if the channel is not live.
ON
Mode 1 : Normal.
Mode 2 : Operates as normal, but the remote start function is only activated by the ON
button, and generates a START whenever the button is pressed while the fader is up.
Mode 3 : Always on and no LED indication. The channel cannot be turned o and the On
button LEDs are never active.
Mode 4 : Always on. The channel cannot be turned o.
Mode 5 : Always on. The LEDs in the ON button are controlled via GPIO.
Mode 6 : Always on. The LEDs in the ON button are controlled via GPIO and the remote
START/STOP functions are generated by the ON button only, but are dependent on the
GPIO state. This mode allows the module to interact with the VCS playout system.
Red LED Green LED State
OFF OFF Not ready. Pressing the ON button will do nothing
ON OFF Ready. Pressing the ON button will generate a START.
OFF ON Playing. Pressing the ON button will generate a STOP.
ON ON Not used.
Mode 7 : Always on. The remote start function is activated whenever the ON button is
pressed, regardless of the fader position.
Mode 8 : Always on. The remote start function is activated whenever the ON button is
pressed and the fader is up or when PFL is active while the fader is down.
S2CDSE/S2CDS DIGITAL DUAL
STEREO LINE CHANNEL WITH &
WITHOUT EQ
9
S2CDSE/S2CDS DIGITAL DUAL STEREO LINE CHANNEL WITH & WITHOUT EQ
