On-Air 2000M2 Digital Mixing Console
Date printed: 26.07.04 SW V 4.0 DIP Switches and Jumpers 16-7
16.8 Monitoring Module
On the Monitoring Controller PCB, all DIP switches must be set to their
OFF position.
16.9 Clock Sync Module
If P7 and P8 are connected with a jumper, the 75 Ω termination of the
VIDEO IN input is active. If this jumper is removed, the input is termi-
nated with 110 Ω.
16.10 Time Sync Module
DIP Switch The external time reference signal for the Time Sync Module is selected
with a DIP switch. The DIP switch setting is displayed in hexadecimal on
the TIME & DATE FORMAT page (TIME SYNC. PROTOCOL field) for
easy verification.
DIP switch no.:
Time source
Hex
Display
1 2 3 4 5 6 7 8
NONE
NONE ON ON ON ON ON ON ON ON*
AFNOR NFS87-500
1 OFF ON ON ON ON ON ON ON*
DCF77
(expert mouse clock)
2 ON OFF ON ON ON ON ON ON*
MOBATIME
(IF482; 9600 baud)
3 OFF OFF ON ON ON ON ON ON*
GPS (NMEA 0183 V1.5, V2.0;
4800 baud)
4 ON ON OFF ON ON ON ON ON*
SEIKO serial clock
(RS485; 2400 baud)
5 OFF ON OFF ON ON ON ON ON*
RCC 8000A (9600 baud)
6 ON OFF OFF ON ON ON ON ON*
HOPF 6021 telegram
(9600 baud)
7 OFF OFF OFF ON ON ON ON ON*
VORTEX 482D
(9600 baud), opt. “0”
8 ON ON ON OFF ON ON ON ON*
LEITCH CSD-5300 (300 baud)
(SMPTE bi-phase TC)
9 OFF ON ON OFF ON ON ON ON*
SMPTE bi-phase input
(LEITCH format)
A ON OFF ON OFF ON ON ON ON*
SEIKO QC-7CF2
B OFF OFF ON OFF ON ON ON ON*
SIPRONIKA SAT520 protocol
(9600, 7E2)
C ON ON OFF OFF ON ON ON ON*
GORGY ASCII format
(2400 baud)
D OFF ON OFF OFF ON ON ON ON*
Reserved for future use
all remaining combinations
* Standard setting: ON
This switch can be set to OFF in order to mask out the
validity bits in some data formats (e.g. it is possible to
use Mobatime data from a Mobatime clock that has no
DCF reception and thus sends “M” instead of “A”)
Jumper Setting
IF type Jumper setting Used for:
RS232C 8-9, 5-6 DCF77, Hopf, MOBA, RCC8000A, Seiko
RS422/RS485 7-8, 4-5 GPS, Leitch (SMPTE TC), AFNOR
Supply (high-Z) 10-11, 12-13 DCF77 or MOBA only!
Note: For DIP switch and jumper locations refer to the drawing on the next page.
