OnAir 2000M2 Digital Mixing Console
Date printed: 12.11.03 SW V 4.0 Machine Control 9-5
9.4 CTRL OUT1/2 & CTRL IN Application Examples
Application
Configuration
CTRL OUT1;
see Note 4
Configuration
CTRL OUT2;
see Note 4
Configuration of
key 3
(“OFF”/LOCATE);
see Note 4
Connection(s) OnAir 2000M2
–> controlled source (e.g.
CD player, cart/tape recorder
Fader start/stop with:
Fader open/close, or channel ON/OFF
ON & FADER — —
CTRL OUT1 –> remote control
input “fader start”
Fader start/stop with:
Fader open/close, or channel ON/OFF, or
PFL ON/OFF
PFL / ON &
FADER
— —
CTRL OUT1 –> remote control
input “fader start”
Review function of Studer D730/D731:
pre-listening with PFL and subsequent locate
to the last cue address. Afterwards: PLAY
with fader start; see Notes 1 and 2
ON & FADER PREVIEW —
CTRL OUT2 –> Studer D730/
D731, remote control input
“SR_REVIEW”; see fig. a)
Pre-listening with PFL and subsequent locate
to the start; console sends an 0.2 s locate
pulse on CTRL OUT2. Afterwards: PLAY with
fader start; see Note 1
PFL / ON &
FADER
LOCATE PFL
KEY
—
CTRL OUT1 –> remote control
input “fader start”, CTRL OUT2
–> remote control input “locate”;
see fig. b)
Manual locate to the start, using
OFF/LOCATE key 3; see Note 1
— LOCATE KEY LOCATE
CTRL OUT2 –> remote control
input “locate”; see fig. b)
Pre-listening with PFL and subsequent locate
to the start. Manual locate also available; see
Note 1
PFL / ON &
FADER
LOCATE PFL /
LOC KEY
LOCATE
CTRL OUT1 –> remote control
input “fader start”; CTRL OUT2
–> remote control input “locate”;
see fig. b)
Fader start pulse and fader stop pulse (on
different control outputs)
ON & FADER
or
PFL / ON &
FADER
FADER STOP
PULSE
—
CTRL OUT1 –> fader start pulse,
CTRL OUT2 –> fader stop pulse;
used for any remote control input
using pulses instead of a static
signal
Control of any external signal with key 3
(“OFF”)
— ATTENTION LOCATE CTRL OUT2 –> any control input
Reflects the ON lamp status to CTRL OUT1 ON LAMP — — CTRL OUT1 –> any control input
Reflects the ON lamp status to CTRL OUT2 — ON LAMP — CTRL OUT2 –> any control input
Note 1: Function is available only if the corresponding console channel is not active; “channel active” = fader open and channel ON
and channel assigned to PGM or REC bus.
Note 2: D730/D731 configuration checksum example, suited for this function: 4050631164470. For more information on this subject,
please refer to the D730/D731 operating instructions manual, order no. 10.27.1672
Note 3: Combination of different applications is possible if allowed by the CTRL OUT1/2 wiring.
Note 4: DO NOT change the settings while any of the control output signals is active!
OnAir 2000M2 D730/D731 CD Player
CTRL IN
CTRL OUT1
BR_PAUSE
FAD1
SR_REVIEWCTRL OUT2
CTRL IN
CTRL OUT1
BR_PAUSE
FAD1
SR_LOCATECTRL OUT2
OnAir 2000M2 D730/D731 CD Player
a)
b)
