OnAir 2000M2 Digital Mixing Console
11-2 User Modes SW V 4.0 Date printed: 12.11.03
11.2 Access Configurable Functions of the Console
Function Description Default User
Normal
User
Adminis-
trator
Loglist management
Accept an entry (delete entry from list) configurable configurable accessible
View the log list accessible accessible accessible
Aux Master
Inserts on AUX page configurable configurable accessible
Aux 1 and 2 parameters configurable configurable accessible
AUDIT master
AUDIT level on TEL N–1 AUDIT page configurable configurable accessible
N–1 master
N–1A/N–1B levels on TEL N–1 AUDIT page configurable configurable accessible
Channel input parameters
Aux 1 parameters:
Set channel input as AF for Aux 1
Set channel input as PF for Aux 1
Add channel input to Aux 1
Remove channel input from Aux 1
Aux 1 level
configurable configurable accessible
Aux 2 parameters:
Set channel input as AF for Aux 2
Set channel input as PF for Aux 2
Add channel input to Aux 2
Remove channel input from Aux 2
Aux 2 level
configurable configurable accessible
Phase parameters:
Set phase to invert
Set phase to normal
configurable configurable accessible
Phantom parameters:
Set phantom to ON
Set phantom to OFF
configurable configurable accessible
Stereo mode parameters:
Set channel to stereo mode
Set channel to mono mode
Set stereo mode to LR
Set stereo mode to LL
Set stereo mode to RL
Set stereo mode to RR
configurable configurable accessible
Gain/cal parameters:
configurable configurable accessible
Pan/balance parameters:
configurable configurable accessible
Sum selection:
Add/remove chn to/from ON-AIR bus
Add/remove chn to/from RECORD bus
configurable configurable accessible
