OnAir 2000M2 Digital Mixing Console
5-6 Master Functions SW V 4.0 Date printed: 12.11.03
5.5 Mixer Setup
The Mixer Setup page gives access to several function groups used for
setting the general status of the console. These are:
Global snapshots, private snapshots, global microphone (mic) settings,
private microphone (mic) settings, global channel routings.
At the left of the Mixer Setup page there is the SNAPSHOTS area. The
five fields allow snapshot selection.
Up to ten mic settings can be selected in the MIC SET area; either all of
them are displayed, or – if the CHAN ROUT section is visible on this page
as well – they are displayed in groups of four and can be browsed using the
NEXT... and/or PREV... fields, as shown above.
Five global channel routings are accessible in the CHAN ROUT area. If no
global channel routings should have been defined by the system adminis-
trator, the CHAN ROUT area is not displayed, as shown below.
The right part of the Mixer Setup page also provides the following com-
mand fields:
PRIVATE/GLOBAL: Users can select between private and global snapshots and mic settings.
SYSTEM CONFIG: This field leads to the second level of mixer setup functions. These are
accessible only for users having the corresponding parameter set in the
user configuration. A new page is displayed, allowing to select from sev-
eral groups of configuration parameters.
ROUTING: This field leads to the CHANNEL ROUTING. page. This page is only
accessible for users having the corresponding access right set in the user
configuration.
The use of snapshots, mic settings, and channel routings is described in the
following chapters, followed by some information on user administration
and the watch/stopwatch functions.
