Studer OnAir 2000M2 User Manual

OnAir 2000M2 Digital Mixing Console
Date printed: 12.11.03 SW V 4.0 Level Meters 6-1
6 LEVEL METERS
The OnAir 2000M2 mixing consoles can be equipped with one or two
stereo level meters, according to customer’s specification.
For the two meters, the sources can be selected in the configuration menu
and are available in analog and digital (AES/EBU) form for the meters:
Meter 1 Meter 2 Source
X X CR MONITOR
X X PROGRAM
X X RECORD
X X AUX 1
X X AUX 2
X AUDIT
X N–1 A
For configuration details refer to chapter 12.2.4.
6.1 Standard Level Meters
The following level meters can be installed as standard:
Digital input
Dual bar graph, PPM, with correlator RTW 11519D STU
Stereo display, dual PM, with correlator RTW 1069 STU
Analog input
Dual bar graph, PPM, with correlator RTW 1119E STU
Dual bar graph, PPM Studer 1.913.611
Dual bar graph, VU Studer 1.913.612
Dual 30-LED, PPM Studer 1.913.605
Dual 30-LED, VU Studer 1.913.606
Dual 30-LED + Dual 10-LED, PPM Studer 1.913.610
Correlator, 30-LED, 2-CH Studer 1.913.609
Correlator, 30-LED, 4-CH,
switchable to meter 1 and 2
Studer 1.913.600
