OnAir 2000M2 Digital Mixing Console
2-2 Hardware SW V4.0 Date printed: 12.11.03
2.1 Input Modules
Each input can be equipped with one of the following modules:
• Mic Input Module (1.942.220)
• Line Input Module, transformer-balanced (1.942.230)
• Line Input Module, electronically balanced (1.942.232)
• Digital Input Module (1.942.240)
• Analog Hex Line Input Module (1.942.245)
• Digital Hex Line Input Module (1.942.250)
All inputs have A/B switchover, except the hex input modules which have
a one-out-of-six input selector.
For details on input modules refer to the Operating Instructions, chapters
15 and 16.
Restrictions: The maximum number of inputs on the OnAir 2000M2 is limited to 64.
Therefore a 12-channel console can be equipped with a maximum of 10
Hex Input Modules (10 × 6 inputs) plus e.g. two Mic Input Modules (2 × 2
inputs).
2.2 Output Modules
Each output can be equipped with analog or digital output modules. Avail-
able output modules are:
• Analog Output Module, transformer-balanced (1.942.120)
• Dual Analog Output Module, transformer-balanced (1.942.121)
• Analog Output Module, electronically balanced (1.942.122)
• Digital Output Module (1.942.124)
For details on output modules refer to the Operating Instructions, chapters
15 and 16.
2.3 Monitoring
The Monitoring Module includes monitoring functions for control room
(CR) and studio. Audio and control signals are handled by this module.
The CR monitoring functions are controlled from the central section of the
user surface. The studio monitoring functions can be controlled either from
the central section of the user surface (source selection) or from a dedi-
cated, simple studio monitor unit (“TB box”, 1.924.555).
For details on the Monitoring Module and the available extensions refer to
the Operating Instructions, chapters 15 and 16.
