AC-34
HVAC SYSTEM (AUTO A/C)(DIAGNOSTIC)
Diagnostic Procedure for Sensors
Step Check Yes No
1 CHECK HARNESS CONNECTOR BETWEEN
AUTO A/C CONTROL MODULE AND COM-
BINATION METER.
1) Turn the ignition switch to OFF.
2) Disconnect the connector from auto A/C
control module and combination meter.
3) Measure the resistance in harness
between auto A/C control module and combi-
nation meter.
Connector & terminal
(i10) No. 30 — (i48) No. 14:
Is the resistance less than 1
Ω?
Go to step 2. Repair the har-
ness between auto
A/C control mod-
ule and combina-
tion meter.
2 CHECK AMBIENT SENSOR CIRCUIT.
Check the ambient sensor circuit. <Ref. to IDI-
8, CHECK OUTSIDE TEMPERATURE INDI-
CATOR, INSPECTION, Combination Meter
System.>
Is the ambient sensor circuit
normal?
Go to step 3. Repair the ambi-
ent sensor circuit.
3 CHECK POOR CONTACT.
Check poor contact in auto A/C control module
connector.
Is there poor contact in con-
nector?
Repair the con-
nector.
Replace the A/C
control module.
