RUN NOW Excite +: Technical Service guide - rev. 6.2
Page 7.48
Figure 7.21-11
To replace the cable-
tie that fix the
autotransformer cable, under the motor, is
necessary proceed as follow:
1. Back off the 5 screw (a) with a 4mm
hexagonal wrench.
2. Remove the lower guard (b).
Figure 7.21-12
3. Replace the cable-
tie making sure the
autotransformer at the frame,
as shown in the
figure at the side.
