ME310G1/ME910G1/ML865G1 AT Commands Reference Guide
80617ST10991A Rev. 11 Page 534 of 1039 2021-09-23
Not Subject to NDA
3.10.5. AT#SLED - STAT_LED GPIO Setting
The command configures the behavior of the STAT_LED status.
SIM Presence
Setting saved
Can be aborted
MAX timeout
SELINT
Not required
Other
No
-
2
AT#SLED=<mode>[,<onDuration>[,<offDuration>]]
STAT_LED is mapped on a GPIO for ME910G1 and ML865G1 families, but it
is on a dedicated pin for ME310G1 family.
To configure a GPIO pin as STAT_LED GPIO, the user must enter
AT#GPIO=x,0,2 command to set the GPIO_x pin as ALT1 alternate function.
At the next power ON, the GPIO pin is low until the control reads the saved
setting in NVM and configures the GPIO_x as STAT_LED GPIO. Not all
GPIOs can be configured as STAT_LED pin. See #GPIO description to know
the available GPIOs for this function.
In case of a dedicated pin for STAT_LED function, there is no GPIO to set in
ALT1 function.
Parameters:
Name
Type
Default
Description
<mode>
integer
N/A
defines the STAT_LED pin behavior.
"pin" indicates the GPIO or the
dedicated pin according to the family
of modules used.
Family
<mode> default
value
ME910G1
2
ML865G1
2
ME310G1
5
Values:
0
:
pin tied low
