Telit Wireless Solutions ML865G1 Reference Guide

ME310G1/ME910G1/ML865G1 AT Commands Reference Guide
80617ST10991A Rev. 11 Page 529 of 1039 2021-09-23
Not Subject to NDA
ALT1 (<dir>=2)
#GPIO maps "STAT_LED" on:
GPIO_01 for ME910G1 family: AT#GPIO=1,0,2
GPIO_08 for ML865G1 family: AT#GPIO=8,0,2
see #SLED to configure the STAT_LED GPIO_x
behavior.
ALT2 (<dir>=3)
#GPIO or #ALARMPIN maps "ALARM" on one of
the available GPIOs.
Example: AT#GPIO=<pin>,0,3
ALT3 (<dir>=4)
#GPIO maps "TEMPMON" on one of the
available GPIOs.
Example: AT#GPIO=<pin>,0,4
ALT4 (<dir>=5)
Reserved
ALT5 (<dir>=6)
Reserved
ALT6 (<dir>=7)
#GPIO maps "FASTSHDN" on one of the
available GPIOs.
Example: AT#GPIO=4,0,7
ALT7 (<dir>=8)
Reserved
ALT8 (<dir>=9)
#GPIO maps "DTR" on GPIO_01 or GPIO_05 for
ME310G1 family
ALT9 (<dir>=10)
#GPIO maps "RING" on GPIO_02 or GPIO_06 for
ME310G1 family
ALT10
(<dir>=11)
#GPIO maps "SIMIN" on one of the available
GPIOs for ME310G1 and ML865G1 families. The
same function can be set through #SIMINCFG
command.
Example: AT#GPIO=5,0,11
ALT11
(<dir>=12)
Reserved
ALT12
(<dir>=13)
#GPIO maps "Network Attach Indicator" on
GPIO_03 for ME310G1 SKT
ALT13
(<dir>=14)
#GPIO maps "TX Packet Monitor" on GPIO_04
for ME310G1 SKT
ALT14
(<dir>=15)
#GPIO maps "RX Packet Monitor" on GPIO_05
for ME310G1 SKT
ALT15
(<dir>=16)
#GPIO maps "DCD" on one of the available
GPIOs for ME310G1 family
