Thermo Fisher Scientific Micro-Tech 9101/9201 Reference Manual, Rev J A-29
Load-Cell Interrupt Selection Jumper
Jumper Jumper Settings Default
J8
Jumper Setting Description
Pins 1-2 Load Cell IRQ 1
Pins 3-4 Load Cell IRQ 2
Pins 5-6 Load Cell IRQ 3
Pins 7-8 Load Cell IRQ 4
J8 Not Installed
Load-Cell Sense Selection Jumpers
Jumper Jumper Settings Default
J14
J15
Jumper Setting Description
Pins 1-2 Local Sense Channel 1
Pins 2-3 Remote Sense Channel 1
Not Installed Remote Sense Channel 1
J14 1-2 Installed
J15 1-2 Installed
J17 Optional R-CAL resistor Channel 1 Not Installed
J19
J20
Jumper Setting Description
Pins 1-2 Local Sense Channel 2
Pins 2-3 Remote Sense Channel 2
Not Installed Remote Sense Channel 2
J19 1-2 Installed
J20 1-2 Installed
J22 Optional R-CAL resistor Channel 2 J22 Not Installed
