A-30 Micro-Tech 9101/9201 Reference Manual, Rev J Thermo Fisher Scientific
Speed-Input and Output #5 Jumpers
Jumper Jumper Settings Default
J24
J25
Speed input 1
Jumper Setting Description
Installed Local 24V Power
Not Installed Remote Power
J24 Installed
J25 Installed
J26
J27
Speed input 2 & Output #5
Jumper Setting Description
Installed Local 24V Power
Not Installed Remote Power
J26 Installed
J27 Installed
J28
J30
J28 Speed input 1 cutoff, J30 Speed input 2 cutoff
Jumper Setting Description
Pins 1-2 Speed Input Cut-off 13kHz
Pins 2-3 Speed Input Cut-off 425 Hz
Not Installed Speed Input Cut-off 13kHz
J28 Installed 1-2
J30 Installed 1-2
