Thermo Scientific Micro-Tech 9101 - Page 226

B-54 Micro-Tech 9101/9201 Reference Manual, Rev J Thermo Fisher Scientific
No.
Parameter
Selection
Description
4
Word length port
#1
8, 7
5
Protocol port #1
Modbus*, Siemens 3964R*, Allen
Bradley DF1*, Printer
*These options are only available when
Printer is selected from Protocol port
#2.
5A
Clear to send #1
Disabled, enabled
Note: This scroll is not available when
Printer is selected for Protocol port #1.
6
Address port #1
1 (1 - 255)
Note: This scroll is not available when
Printer is selected for Protocol port #1.
7 Acces prot port #1 None, limited, protected Note: This scroll is not available when
Printer is selected for Protocol port #1.
8
Baud Rate port #2
9600, 19200, 110, 150, 300, 600,
1200, 2400, 4800
Note: Only available when COMM
board is installed.
9
Set parity port #2
No Parity, even parity, odd parity
Note: Only available when COMM
board is installed.
10
Stop bits port #2
1, 2
Note: Only available when COMM
board is installed.
11
Word length port
#2
8, 7
Note: Only available when COMM
board is installed.
12
Protocol port #2
Printer, Modbus*, Siemens*, A/B
DF1*
Note: This scroll is only available when
COMM board is installed.
*These options are only available when
Printer is selected from Protocol port
#1
12A Clear to send #2 Disabled, Enabled Note: This scroll is not available when
Printer is selected for Protocol port #2.
13
Address port #2
1 (1 - 255)
Note: This scroll is not available when
Printer is selected for Protocol port #2.
14
Acces prot port #2
none, limited, protected
Note: This scroll is not available when
Printer is selected for Protocol port #2.
15
Half duplex delay
0 msec (0 - 50 msec)
Note: This scroll is only available when
a protocol other than Printer is selected
for either Protocol port #1 or Protocol
port #2.
