C-32 Micro-Tech 9101/9201 Reference Manual, Rev J Thermo Fisher Scientific
Response Message
address xxx
function 03H
byte count xxx
data MSB xxx
. . . xxx
data LSB xxx
crc16 lo xxx
crc16 hi xxx
Example 2: Host Wants to Receive the Batch Setpoint
Set point = 100.0 Tons
Address of Slave (Micro-Tech) = 01
Host (PLC) Slave (Micro-Tech)
Address 01H →
Function 03H
Add HI 00H
Add LO 6CH
N Data HI 00H
N Data LO 02H
crc 04H
crc 16H →
← Address 01H
Function 03H
Byte count 04H
Data MSB 00H
Data 00H
Data 42H
Data LSB C8H
crc CBH
← crc 05H
