Example 3: Message of Data Sending from Host (PC or PLC) to
Micro-Tech (code 10H)
Query
address xxx
function 10H
add hi xxx
add lo xxx
n data hi xxx
n data lo xxx
n bytes xxx
data MSB xxx
. . . xxx
data LSB xxx
crc16 lo xxx
crc16 hi xxx
Response Message
address xxx
function 10H
add hi xxx
add lo xxx
n data hi xxx
n data lo xxx
crc16 lo xxx
crc16 hi xxx
Example 4: Host Wants to Write the Batch Setpoint
Batch setpoint = 100.0 Tons
Address of Micro-Tech (Slave) = 1
Host (PLC) Slave (Micro-Tech)
01H →
