C-40 Micro-Tech 9101/9201 Reference Manual, Rev J Thermo Fisher Scientific
Host (PLC) Slave (Micro-Tech)
SIZE OF DATA IN ELEMENTS (LOW)
SIZE OF DATA IN ELEMENTS (HIGH)
DLE 10H
ETX 03H
BCC →
← DL 10H
ACK 06H
Example 2: The Host (PLC) Asks for Data from the Micro-Tech
This message is sent from the Host to the Micro-Tech to request a certain number of data.
Host (PLC) Slave (Micro-Tech)
DLE 10H →
ENQ 05H
ADDRESS SLAVE
BCC →
DLE 10H
STX 02H
ADDRESS HOST
ADDRESS SLAVE
4FH (COMMAND)
STS 00H
TMS xxH
TMS xxH
TYPE DATA
PARAMETER
DATA LSB MSB
. . .
DATA LSB MSB
DLE 10H
ETX 03H
← BCC
To Next Page
