Thermo Fisher Scientific Micro-Tech 9101/9201 Reference Manual, Rev J C-41
Host (PLC) Slave (Micro-Tech)
DLE 10H →
ACK 06H →
Example 3: The Host Sends Data to the Micro-Tech
This message is used by the Host to download registers to the Micro-Tech.
Host (PLC) Slave (Micro-Tech)
DLE 10H →
SOH
ADDRESS OF SLAVE
DLE
STX
ADDRESS SLAVE
ADDRESS HOST
COMMAND 0FH
STS 00H
TMS xxH
TMS xxH
FNC 67H
PACKET OFFSET (LOW)
PACKET OFFSET (HIGH)
TOTAL TRANS (LOW)
TOTAL TRANS (HIGH)
ADDRESS OF DATA (FIRST BYTE)
ADDRESS OF DATA (SECOND BYTE)
ADDRESS OF DATA (THIRD BYTE)
ADDRESS OF DATA (FOURTH BYTE)
TYPE DATA PARAMETER
DATA LSB MSB
. . .
DATA LSB MSB
