OPUS Projektor Manual
Object Reference
· Layer 3: Numbers and special characters
A numeric keyboard only has one layer with the numbers.
Default value: Layer 1
Possible values: Any available layer
This property has no effect on runtime, it only shows the different layers in the designer
area.
Background Color
The background color of the virtual keyboard.
Default color: black (RGB 0, 0, 0)
Possible values: any 24Bit RGB color
Key Background Image
An image can be selected with this property that is then used as background image for all
buttons on the virtual keyboard.
Default value: A default background image
Possible values: Any supported image or no image
Key Background Color
The background color for all buttons in the virtual keyboard can be selected with this
property. The background color of the buttons is only visible if a Key Background Image
(see above) with transparent areas is used or no background image is set.
Default value: grey (RGB 153, 153, 153)
Possible values: Any 24Bit RGB color
Draw Border
With this property the Draw Border property of all buttons in the virtual keyboard can be
enabled or disabled. Enable it if the user shall be able to navigate the buttons via encoder.
If only touchscreen input is used, this property can be disabled.
Default value: Enabled
Possible values: Enabled or Disabled
Font Attribute
The font attribute for all buttons in the virtual keyboard can be selected with this property.
Default value: Default_DejaVu Serif
Possible values: Any font attribute defined in project properties
Font
The font that is used for all buttons in the virtual keyboard can be selected with this property.
Default value: DejaVu Serif
Possible values: Any available font
VKBButton Specific properties
Virtual keyboard buttons are basically normal button objects that have some additional
properties.
The virtual keyboard buttons are language dependent by default.
Button Type
A virtual keyboard button can have one of the following types:
· Character
