How to create dynamic icons
You want to put 40 icons in your UI, but you only have space for 10, so you want to display
them dynamically.
· Create a list object
· Put a String Field in as the first child, delete its text and make it transparent. This will be
shown when no icon needs to be displayed.
· Put all images into the list object
· Create 9 shallow copies of the list object. Now you have the 10 icon "spaces". Put them
where they should be in the UI.
· Create 10 variables and reference one of them to each list object. The variables will switch
the shown icon in each list object.
· Create another variable, "icon_event_flag". This variable will be used as a trigger to refresh
the icons.
· Create a script for the event OnProjektInit. Fill it with this code:
//Definition of the variable names for the listen objects
icon_variable_names = ["New Variable_1","New Variable_2","New Variable_3","New
Variable_4",<until 10>];
num_icons = 40;//global variable with number of icons
num_lists = 4;//global variable with number of list objects
icon_enable = [];//global array to switch each icon visible
//initialize all icons with 0
for (var i = 0; i < num_icons; i++)
{
icon_enable[i] = 0;
}
· Create a script show_icons.js with this code:
//always start with the first list object
var list_position = 1;
//set all list objects transparent first
for (var i = 0; i < num_lists; i++)
{
setVariableValue(icon_variable_names[i],0);
}
//go through icon list and show icon if necessary
for (var i = 0; i < num_icons; i++) {//go through all icons
if (icon_enable[i] !== 0)//check if icon i should be shown
{
setVariableValue(icon_variable_names[list_position-1],(i+1));//show icon i at
position "list_position"
list_position = list_position + 1;//increase list_position to next value
}
}
· Put this script to the event OnValueChange of the variable "icon_event_flag".
· For each event that should show a certain icon, put this code in a script:
icon_enable[<n>] = 1;//show Icon n
//change flag
var flag = getVariableValue("icon_event_flag");
flag = flag + 1;
setVariableValue("icon_event_flag", flag);
