OPUS Projektor Manual
CAN
Value for Status read
from DM1 messages
(Byte 1)
Value for Flashing
read from DM1
messages (Byte 2)
value of
@XXXLampStatus
value of
@XXXLampFlashing
1
2
6
0: Lamp Off
1
3
7
1: Lamp On
2
0
8
0: Lamp Off
2
1
9
0: Lamp Off
2
2
10
0: Lamp Off
2
3
11
0: Lamp Off
3
0
12
0: Lamp Off
3
1
13
0: Lamp Off
3
2
14
0: Lamp Off
3
3
15
0: Lamp Off
As can be seen in the table above the status 2 and 3 for the lamp status and value 2 for
flashing will always switch off the flashing variable. If the used ECUs support these states, a
custom handling of these values needs to be developed manually by using the value of the
@XXXLampStatus variables.
If multiple ECUs send DM1 messages, the lamp stati and flashing information will be
combined from all messages. The priority (highest to lowest) is: Fast Flashing, Slow Flashing,
On, Off.
To enable the calculations for the lamp variables DM1 support needs to be enabled.
5.4
Import DBC File
Tutorial video of the DBC import
https://www.youtube.com/watch?v=4JgRJyLcjRE
Please note that this feature has to be bought first. Contact your vendor to obtain a license.
Without a license, it is not possible to import the content of a DBC file.
Disclaimer!
Please always validate your DBC file in Vector before importing it. This will ensure
that the import works and the functionality is as expected.
If you have problems importing a DBC file and you don't think it's a problem in the
file, please send the file to your vendor for analysis.
