OPUS Projektor Manual
User Interface
If the tool Version > 1.9.x is used and a project with a lower version (< 1.9.x) is opened the
project is automatically converted for new Image Handling.
After the conversion of the project, all scaled images will be recreated and renamed. This
step is necessary to avoid duplicate images.
For recreating the scaled images the original images must be available. By missing of the
original images, the old scaled images are used but they will be renamed in any cases to
new format according rules described in Image Naming Chapter.
Note:
If it is not desired that the scaled images are recreated, you can delete all images in the
"original_images" folder before converting the project. Then all old scaled images are not
recreated.
For performance reason, this step it is not recommended!
Consistency Check
The new Image Handling has a "Consistency Check" which is performed after every
"Save" and "Load" actions. This Check ensures that all images which are used in the
project are stored in "terminal_files" folder. If images are missing they will be created
again. But the "Consistency Check" can only be performed properly if the original images
are available in "original_images" folder. If a scaled image is not available in
"terminal_files" folder, it will not be visible in the tool.
Supported Image Files
The supported image formats are listed here .
3.11.2
Languages
3.11.3
Units
This feature is always a little bit misleading. The tool and the run time on the device do not
offer any pre-defined calculations like Celsius to Fahrenheit and vice versa. You can see the
groups of units in the project properties in the Unit category.
