OPUS Projektor Manual
Object Reference
Default value: Disabled
Possible values: Enabled or Disabled
Offset, Scale, Offset 2
Two offsets and a scale value can be defined that will be used in the following way:
displayed value = (original value + Offset 1) * scale + Offset 2
offsets:
Default value: 0.0
Possible values: -2147483648.0 ... 2147483647.0
scale:
Default value: 1.0
Possible values: -2147483648.0 ... 2147483647.0
Values can be entered in decimal form or in scientific notation / floating-point
representation.
No Of Decimals
The number of decimals property allows to define how many digits will be displayed behind
the decimal point.
Note that values behind the decimal point can only be displayed if the Scale property is not
1.0.
Default value: 1
Possible values: 0 ... 10
Events
The following events can be configured for the numeric field object:
· OnOpenForInput
· OnEnabledWithFocus
· OnEnabledWithoutFocus
· OnValueChange
· OnEnterValue
· OnEnterNewValue
· OnEscape
See here for the descriptions of all event and possible actions that can be assigned.
6.4.13
Picture Graphic
The Picture Graphic object is a simple object to display static images on the screen.
It is also capable of displaying animated GIF images that makes it possible to show small
movies and animations. See GIF properties below.
Note: A free online GIF editor / creator can be found here.
The picture graphic shares some common properties with other objects.
