Topcon OPUS A6G2 - Linear Bargraph

475
OPUS Projektor Manual
Object Reference
The following events can be configured for the button object:
· OnPress
· OnRelease
· OnLongPress
· OnLongRelease
· OnDblClick
· OnOpenForInput
· OnEnabledWithFocus
· OnEnabledWithoutFocus
· OnValueChange
· OnCancel
See here for the descriptions of all event and possible actions that can be assigned.
6.4.8
Linear Bargraph
The linear bargraph is an object for showing a numerical value in a graph.
The linear bargraph shares a lot of common properties with other objects. See here for a
description. Here only the linear bargraph specific properties are described.
Download this project to see an example how to use the linear bargraph. A PDF is included
which explains how the project works.
Linear Bargraph Specific Properties
Direction
The direction of the fill or value line of the bargraph.
For vertical bargraphs a positive direction means that the value grows from bottom to top.
A negative direction means that the value grows from top to bottom.
For horizontal bargraphs a positive direction means that the value grows from left to right. A
negative direction means that the value grows from right to left.
Default value: Positive
Possible values: Positive or Negative
Axis Orientation
A bargraph can either be vertical or horizontal. Depending on this property the drawing of
the bargraph itself and the value changes accordingly.
Default value: Vertical
Possible values: Vertical or Horizontal
Draw Target Line (Theme dependent)
When enabling this property, a line will be drawn at the position of the Target Value
property value.
Default value: Enabled
Possible values Enabled or disabled.
Target Line Color (Theme dependent)
The color in which the target line (see above) will be drawn.
Default value:black (RGB 0, 0, 0)
