Possible values: Any Font Attribute Object defined in project properties .
Absolute Min Value
As the name implies, the Absolute Min Value is the lowest value that a user can set to an
object (Min Value is not, see above).
This property is available only for Arched Bargraph, Linear Bargraph, Meter and Numeric
Field objects.
Following rule applies: Absolute Max Value needs to be greater or equal to Max Value.
Default value: 0
Possible values: Anything less or equal to Min Value but not less than -2147483648
(Absolute Min Value <= Min Value <= Max Value <= Absolute Max Value)
Color Below Minimum
This property defines the color of the object if the value of the object is less than Min Value
(see below).
Color Below Min Value is available for the following objects with the following appearance
effect:
·
Arched Bargraph: Fill color of the bargraph or value line color
·
Linear Bargraph: Fill color of the bargraph or value line color
·
Meter: Needle color
·
Numeric Field: Color of the displayed number
Default value: object specific
Possible values: Any 24Bit RGB color
Preview Value
With the Preview Value property, the value of the object in the designer area can be
previewed. If no variable is referenced to the object, the Preview Value will also be the
value that is displayed at the object at runtime.
The Preview Value property is available for all objects except for the button object (use
Pressed State button property for preview).
Default Value: object specific
Possible values:
·
String field: Any string that is shorter than Max String Length (characters)
·
Integer objects: A value greater than or equal to Absolute Min Value and less than or
equal to Absolute Max Value (Absolute Min Value <= Preview Value <= Absolute
Max Value)
Target Value
The Target Value property is only available for Arsched Bargraph and Linear Bargraph
objects. If the Draw Target Line property for these objects is enabled, a line will be drawn at
the Target Value position.
Default value: 80
Possible values: A value greater than or equal to Absolute Min Value and less than or equal
to Absolute Max Value (Absolute Min Value <= Target Value <= Absolute Max Value)
Activate Low Pass Filter
With this property a low pass filter for the selected object can be activated. A low pass filter
makes the displayed value changes more smooth and can reduce flickering of values.
To adjust the strength of the filter use the property Filter Factor (see below).
The formula for the low pass filter is:
