CurrentValueToDisplay = ((oldValue * filterFactor) + (meassuredValue * (1000 -
filterFactor))) / 1000
This calculation is made in a relatively high frequency until currentValueToDisplay is equal
to meassuredValue.
Default value: Disabled
Possible values Enabled or disabled
This property is available only for Arched Bargraph, Linear Bargraph, Meter and Numeric
Field objects.
Filter Factor
The Filter Factor property is responsible for controlling the strength of the low pass filter
(see Activate Low Pass Filter above).
The higher the value is, the stronger the value changes will be filtered. Best way to find the
best a good value for an object is to try and test some different values.
Default value: 500
Possible values: 0 (almost no filter) ... 1000 (very strong filter)
This property is available only for Arched Bargraph, Linear Bargraph, Meter and Numeric
Field objects if the Activate Low Pass Filter property is enabled.
Step Width
The Step Width property can be used for rounding the value of a Numeric Field. It is
considered both for input by the user and for displaying variable values.
If e.g. a step with of 10 is set, the user can only set values that are multiple of 10 (0, 10, 20,
30, etc.). Also the value of a referenced variable will be rounded (e.g. variable value: 7 =>
displayed value: 10, variable value: 42, displayed value: 40).
Default value: 1
Possible values: 1 ... 2147483647
Font Attribute (Theme dependent)
A Font Attribute provides the size color and style (standard, bold, italic) of how a font shall
be displayed. Font attributes can be created in the project properties .
With the Font Attribute property one of the created Font Attribute Objects can be assigned
to the selected object.
If the font of the object shall be changed use property Font (see below).
Default value: Default_DejaVu Serif
Possible values: Any Font Attribute object defined in project properties .
This property is only available for Numeric Field, String Field and table objects.
Font
The font that shall be displayed in a Numeric Field, String Field or a Table can be selected
using the Font property.
Note that the size and style of the font is controlled via the Font Attribute property (see
above).
Default value:
·
Numeric Field: DejaVu Sans
·
String Field: DejaVu Serif
Possible values: Any pre defined or imported font .
