OPUS Projektor Manual
OPUS devices update manual
Please note that the boot logo cannot be changed with these devices like it can for OPUS
devices. If you need to change the boot logo, please contact opus-support@topcon.com
14.3
Updating the device
In this chapter, the update process for the different device types is described.
14.3.1
OPUS A3 / A6 G1
The first step to update the device is to copy the update files on a USB stick. The USB
stick has to be FAT32 formatted with only one partition.
Copy the OS and/or the files for the application that should run on the device into the root
folder of the USB stick. The USB stick may contain other data, they will be ignored.
You can find the update files in the extracted zip file that you downloaded / got on your USB
stick.
In Windows, the user.tar files are often shown as zip files.
Never unzip these files or the update won't work!
For OPUS Projektor: Starting from OPUS / WE Toolchain 1.11, the update files for the
devices are included in the Projektor Tool. Go to the menu Update -> PClient / OS Update. In
the dialog you can choose for which device you want to copy the OS and PClient files on the
USB stick.
For older versions, check the downloaded zip file:
\PClient\OPUSAx\OPUSA3L(andscape)_BSP_PClient_Update (for landscape, for portrait
it’s OPUSA3P(ortrait)_BSP_PClient_Update)
For ISO-VT: \OPUS Ax
For Codesys: \CustomerFiles\Device\OPUSAx
Power off the device and connect the USB stick with the update files with the USB port
of the device (both the front USB slot and the USB cable from the main connector can be
used).
There are two ways to start the device in update mode, you can use either one of them
(but you don’t need to do both!):
a) Connect the clamp “Serv_EN” (service enable) with clamp 15 and 30 and then
power on the device.
