This property defines the color of the object if the value of the object is greater than Max
Value (see below).
Color Above Max Value is available for the following objects with the following appearance
effect:
·
Arched Bargraph: Fill color of the bargraph or value line color
·
Linear Bargraph: Fill color of the bargraph or value line color
·
Meter: Needle color
·
Numeric Field: Color of the displayed number
Default value: object specific
Possible values: Any 24Bit RGB color
Max Value
The Max Value property is a threshold for doing the color change to Color Above
Maximum when the value of the object is greater than the value of Max Value.
This property is available only for Arched Bargraph, Linear Bargraph, Meter and Numeric
Field objects.
Default value: depends on object:
·
Arched Bargraph and Meter: 300
·
Linear Bargraph: 80
·
Numeric Field: 90
Possible values: Any value greater than or equal to Min Value and less than or equal to
Absolute Max Value (Absolute Min Value <= Min Value <= Max Value <= Absolute Max
Value)
Font Attribute Above Max Value (Theme dependent)
This property defines the Font Attribute that is used when the value of the object is above
Max Value.
This property is only available for the Numeric Field object.
To learn more about Font Attribute Objects see here .
Default value: Default_DejaVu Sans
Possible values: Any Font Attribute Object defined in project properties .
Min Value
The Min Value property is a threshold for doing the color change to Color Below
Minimum when the value of the object is less than the value of Min Value.
This property is available only for Arched Bargraph, Linear Bargraph, Meter and Numeric
Field objects.
Default value: depends on object:
·
Arched Bargraph, Linear Bargraph and Meter: 20
·
Numeric Field: 10
Possible values: Any value greater than or equal to Absolute Min Value and less than or
equal to Max Value (Absolute Min Value <= Min Value <= Max Value <= Absolute Max
Value)
Font Attribute Below Min Value (Theme dependent)
This property defines the Font Attribute that is used when the value of the object is below
Min Value.
This property is only available for the Numeric Field object.
To learn more about Font Attribute Objects see here .
Default value: Default_DejaVu Sans
