OPUS Projektor Manual
CAN
bits 8-7
Malfunction
Indicator
Lamp Status
bits 4-3
Amber
Warning
Lamp Status
bits 2-1
Protect
Lamp Status
and a flashing indicator (byte 2):
bits 8-7
Flash
Malfunction
Indicator
bits 6-5
Flash Red
Stop Lamp
bits 4-3
Flash Amber
Warning
Lamp
bits 2-1
Flash Protect
Lamp
There are 8 predefined internal variables available that represent these values (read-only).
The variables are available in the group J1939 and are named
· @MalfunctionIndicatorLampStatus
· @RedStopLampStatus
· @AmberWarningLampStatus
· @ProtectLampStatus
· @MalfunctionIndicatorLampFlashing
· @RedStopLampFlashing
· @AmberWarningLampFlashing
· @ProtectLampFlashing
The @XXXLampStatus contains the combined information of the status and flashing bits in
the DM1 message with 16 possible combinations. The @XXXLampFlashing variable
contains the direct "is it on or not?" information, when the lamp is flashing, it will change value
between 0 and 1, if the lamp should glow, it will stay 1. So normally only the
@XXXLampFlashing variable is needed to display the lamps by creating a list object with two
images (an on and an off lamp image) and connecting it with the @XXXLampFlashing
variable.
The following table shows the possible values of the DM1 message bytes and our variables.
The calculation is the same for all the four variables:
Value for Status read
from DM1 messages
(Byte 1)
Value for Flashing
read from DM1
messages (Byte 2)
value of
@XXXLampStatus
value of
@XXXLampFlashing
0
0
0
0: Lamp Off
0
1
1
0: Lamp Off
0
2
2
0: Lamp Off
0
3
3
0: Lamp Off
1
0
4
0/1: Flashing 1Hz
1
1
5
0/1: Flashing 2Hz
