462
OPUS Projektor Manual
Object Reference
· Start Angle 0, End Angle 360:
· Start Angle 0, End Angle 315:
· Start Angle 45, End Angle 0:
· Start Angle 135, End Angle 225:
· Start Angle 315, End Angle 225:
Arched Bargraph Specific Properties
Start Angle
The start angle of the arched bargraph can be defined with this property.
The start angle's 0° position is at 3 o clock.
Default value: 0°
Possible values: 0° ... 360°
See examples above
End Angle
The end angle of the arched bargraph can be defined with this property.
The start angle's 0° position is at 3 o clock.
Default value: 0°
Possible values: 0° ... 360°
