OPUS Projektor Manual
Simulations
·
The variable name
·
The current variable value as reported by the PClient
o If the value of the variable is grey, the value of the variable is invalid
o If the value of the variable is black, the value of the variable is valid
·
Automatic Value Generator Play and Resume buttons
o If a generator was configured for this variable and the generator settings are in the
valid range for that variable, the buttons are enabled and can be clicked
o If no generator is configured for the variable or the generator settings contain
invalid values, the buttons are disabled
·
The "Mode" column show how the current value was set:
o PClient: The value was retreived by PClient. The simulation did not change the
value (yet).
o Manual: The value was manually changed via the manual value change by the
simulation.
o Auto: The value was changed by an automatic value generator .
o Stopped: An automatic value generator was just stopped
By clicking on a variable node, the value operations view and the variable properties
view will be populated with the data of the selected variable.
Favorites
Add and remove favorites
To add a variable as a favorite simply right-click on the variable. In the context menu select
"Add to Favorites".
To remove a variable from the favorites simply click on the variable with the right mouse
button. In the popup menu select "Remove from Favorites".
When a variable was added to the favorites, it's name will appear bold in the variable tree.
It is also possible to select multiple variables and add or remove them from the favorites
list. Simply hold the CTRL key while selecting multiple variables with the left mouse button.
When the desired variables are selected, do a right-click on one of the selected variables
and follow the description above to add or remove all selected variables to/from the
favorites.
To add or remove all variables of one group to or from the favorites, right-click on the group
and follow the instructions above (Note that only the variables inside the group will be
displayed bold when they are favorites, not the group itself).
Show only favorite variables
To only show favorites in the variable tree, enable the checkbox "Show Favorites Only"
below the variable tree.
To show all variables, remove the check mark from the "Show Favorites Only" checkbox.
Hide pre-defined variables
A project contains a lot of pre-defined variables that might render the variable tree a little
confusing. To hide the pre-defined variables and only show user created variables set the
checkmark in the "Hide Pre-Defined Variables" checkbox.
Filter / Search
