OPUS Projektor Manual
OPUS devices update manual
Warning: When upgrading to OS EGSPRO 2.x, a downgrade to
EGSPRO 1.x is NOT POSSIBLE!
In Windows, the user.tar files are often shown as zip files.
Never unzip these files or the update won't work!
To update from EGSpro 1.x to EGSpro 2.x, the additional files
update.img and update.img.md5 must be included on the
update USB stick.
To update from EGSpro 1.x or 2.x to EGSpro 3.x, the additional
files update.img and update.img.md5 must be included on the
update USB stick.
For OPUS Projektor: Starting from OPUS / WE Toolchain 1.11, the update files for the
devices are included in the Projektor Tool. Go to the menu Update -> PClient / OS Update. In
the dialog you can choose for which device you want to copy the OS and PClient files on the
USB stick.
For older versions:
\PClient\EGSPRO\OPUSA3L(andscape)_BSP_PClient_Update (for landscape, for portrait
it’s OPUSA3P(ortrait)_BSP_PClient_Update)
For ISO-VT: \EGSPRO
For Codesys: \CustomerFiles\Device\EGSPRO
Power off the device and connect the USB stick with the update files with the USB port
of the device (both the front USB slot and the USB cable from the main connector can be
used). Connect the clamp “Serv_EN” (service enable) with clamp 15 and 30 and then
power on the device.
