Trango Systems, Inc. GigaPlus User Manual Rev 3.1 235
Outdoor Unit
Part Numbers
Description
TX Freq
Min*
(MHz)
TX Freq
Max*
(MHz)
Diplexer
Range
(MHz)
Max
Chan
Size
(MHz)
HP2-08-0266-1A ODU, HP2 8Ghz, ETSI TR266, 1A 7,905 8,024 119 56
HP2-08-0266-1B ODU, HP2 8Ghz, ETSI TR266, 1B 8,171 8,290 119 56
HP2-08-0266-2A ODU, HP2 8Ghz, ETSI TR266, 2A 8,017 8,136 119 56
HP2-08-0266-2B ODU, HP2 8Ghz, ETSI TR266, 2B 8,283 8,402 119 56
HP1-08-0266-1A ODU, HP 8Ghz, ETSI TR266, 1A 7,905 8,024 119 56
HP1-08-0266-1B ODU, HP 8Ghz, ETSI TR266, 1B 8,171 8,290 119 56
HP1-08-0266-2A ODU, HP 8Ghz, ETSI TR266, 2A 8,017 8,136 119 56
HP1-08-0266-2B ODU, HP 8Ghz, ETSI TR266, 2B 8,283 8,402 119 56
HP2-08-0311-1A ODU, HP2 8Ghz, ETSI TR311, 1A 7,731 7,867 136 56
HP2-08-0311-1B ODU, HP2 8Ghz, ETSI TR311, 1B 8,042 8,178 136 56
HP2-08-0311-2A ODU, HP2 8Ghz, ETSI TR311, 2A 7,835 7,971 136 56
HP2-08-0311-2B ODU, HP2 8Ghz, ETSI TR311, 2B 8,146 8,282 136 56
HP1-08-0311-2A ODU, HP 8Ghz, ETSI TR311, 2A 7,835 7,971 136 56
HP1-08-0311-2B ODU, HP 8Ghz, ETSI TR311, 2B 8,146 8,282 136 56
HP1-08-0311-3A ODU, HP 8Ghz, ETSI TR311, 3A 7,717 7,867 150 56
HP1-08-0311-3B ODU, HP 8Ghz, ETSI TR311, 3B 8,028 8,178 150 56
HP ODUs,- 10 GHZ
HP2-10-0350-1A ODU, HP2 10Ghz, ETSI TR350, 1A 10,150 10,300 150 56
HP2-10-0350-1B ODU, HP2 10Ghz, ETSI TR350, 1B 10,500 10,650 150 56
HP ODUs,- 10.5 GHZ
HP2-10-091-1A ODU, HP2 10.5Ghz, ANSI TR91, 1A 10,500 10,531 30 30
HP2-10-091-1B ODU, HP2 10.5Ghz, ANSI TR91, 1B 10,591 10,622 30 30
HP2-10-091-2A ODU, HP2 10.5Ghz, ANSI TR91, 2A 10,528 10,559 30 30
HP2-10-091-2B ODU, HP2 10.5Ghz, ANSI TR91, 2B 10,619 10,650 30 30
HP2-10-091-3A ODU, HP2 10.5Ghz, ANSI TR91, 3A 10,556 10,587 30 30
HP2-10-091-3B ODU, HP2 10.5Ghz, ANSI TR91, 3B 10,647 10,678 30 30
HP ODUs, – 11 GHZ
HP2-11-0490-5A ODU, HP2 11Ghz, ANSI/ETSI TR490/500, 5A 10,700 10,890 190 56
HP2-11-0490-5B ODU, HP2 11Ghz, ANSI/ETSI TR490/500, 5B 11,200 11,390 190 56
HP2-11-0490-6A ODU, HP2 11Ghz, ANSI/ETSI TR490/500, 6A 10,855 11,045 190 56
HP2-11-0490-6B ODU, HP2 11Ghz, ANSI/ETSI TR490/500, 6B 11,355 11,545 190 56
HP2-11-0490-7A ODU, HP2 11Ghz, ANSI/ETSI TR490/500, 7A 11,010 11,200 190 56
HP2-11-0490-7B ODU, HP2 11Ghz, ANSI/ETSI TR490/500, 7B 11,510 11,700 190 56
HP1-11-0490-5A ODU, HP 11Ghz, ANSI/ETSI TR490/500, 5A 10,700 10,890 190 56
HP1-11-0490-5B ODU, HP 11Ghz, ANSI/ETSI TR490/500, 5B 11,200 11,390 190 56
HP1-11-0490-6A ODU, HP 11Ghz, ANSI/ETSI TR490/500, 6A 10,855 11,045 190 56
HP1-11-0490-6B ODU, HP 11Ghz, ANSI/ETSI TR490/500, 6B 11,355 11,545 190 56
HP1-11-0490-7A ODU, HP 11Ghz, ANSI/ETSI TR490/500, 7A 11,010 11,200 190 56
HP1-11-0490-7B ODU, HP 11Ghz, ANSI/ETSI TR490/500, 7B 11,510 11,700 190 56
HP2-11-0530-1A ODU, HP2 11Ghz, ETSI TR530, 1A 10,675 10,855 180 56
HP2-11-0530-1B ODU, HP2 11Ghz, ETSI TR530, 1B 11,205 11,385 180 56
HP2-11-0530-2A ODU, HP2 11Ghz, ETSI TR530, 2A 10,795 10,975 180 56
HP2-11-0530-2B ODU, HP2 11Ghz, ETSI TR530, 2B 11,325 11,505 180 56
HP2-11-0530-3A ODU, HP2 11Ghz, ETSI TR530, 3A 10,915 11,135 220 56
HP2-11-0530-3B ODU, HP2 11Ghz, ETSI TR530, 3B 11,445 11,665 220 56
HP2-11-0530-4A ODU, HP2 11Ghz, ETSI TR530, 4A 11,035 11,215 180 56
HP2-11-0530-4B ODU, HP2 11Ghz, ETSI TR530, 4B 11,565 11,745 180 56
HP1-11-0530-1A ODU, HP 11Ghz, ETSI TR530, 1A 10,675 10,855 180 56
HP1-11-0530-1B ODU, HP 11Ghz, ETSI TR530, 1B 11,205 11,385 180 56
HP1-11-0530-2A ODU, HP 11Ghz, ETSI TR530, 2A 10,795 10,975 180 56
HP1-11-0530-2B ODU, HP 11Ghz, ETSI TR530, 2B 11,325 11,505 180 56
HP1-11-0530-3A ODU, HP 11Ghz, ETSI TR530, 3A 10,915 11,135 220 56
HP1-11-0530-3B ODU, HP 11Ghz, ETSI TR530, 3B 11,445 11,665 220 56
HP1-11-0530-4A ODU, HP 11Ghz, ETSI TR530, 4A 11,035 11,215 180 56
HP1-11-0530-4B ODU, HP 11Ghz, ETSI TR530, 4B 11,565 11,745 180 56
