Trango Systems, Inc. GigaPlus User Manual Rev 3.1 236
Outdoor Unit
Part Numbers
Description
TX Freq
Min*
(MHz)
TX Freq
Max*
(MHz)
Diplexer
Range
(MHz)
Max
Chan
Size
(MHz)
HP ODUs, – 13 GHZ
HP2-13-0225-1A ODU, HP2 13Ghz, ANSI TR225, 1A 12,700 12,815 115 56
HP2-13-0225-1B ODU, HP2 13Ghz, ANSI TR225, 1B 12,925 13,040 115 56
HP2-13-0225-2A ODU, HP2 13Ghz, ANSI TR225, 2A 12,755 12,870 115 56
HP2-13-0225-2B ODU, HP2 13Ghz, ANSI TR225, 2B 12,980 13,095 115 56
HP2-13-0225-3A ODU, HP2 13Ghz, ANSI TR225, 3A 12,810 12,925 115 56
HP2-13-0225-3B ODU, HP2 13Ghz, ANSI TR225, 3B 13,035 13,150 115 56
HP2-13-0266-1A ODU, HP2 13Ghz, ETSI TR266, 1A 12,751 12,814 63 56
HP2-13-0266-1B ODU, HP2 13Ghz, ETSI TR266, 1B 13,017 13,080 63 56
HP2-13-0266-2A ODU, HP2 13Ghz, ETSI TR266, 2A 12,807 12,870 63 56
HP2-13-0266-2B ODU, HP2 13Ghz, ETSI TR266, 2B 13,073 13,136 63 56
HP2-13-0266-3A ODU, HP2 13Ghz, ETSI TR266, 3A 12,863 12,926 63 56
HP2-13-0266-3B ODU, HP2 13Ghz, ETSI TR266, 3B 13,129 13,192 63 56
HP2-13-0266-4A ODU, HP2 13Ghz, ETSI TR266, 4A 12,919 12,982 63 56
HP2-13-0266-4B ODU, HP2 13Ghz, ETSI TR266, 4B 13,185 13,248 63 56
HP1-13-0266-1A ODU, HP 13Ghz, ETSI TR266, 1A 12,751 12,814 63 56
HP1-13-0266-1B ODU, HP 13Ghz, ETSI TR266, 1B 13,017 13,080 63 56
HP1-13-0266-2A ODU, HP 13Ghz, ETSI TR266, 2A 12,807 12,870 63 56
HP1-13-0266-2B ODU, HP 13Ghz, ETSI TR266, 2B 13,073 13,136 63 56
HP1-13-0266-3A ODU, HP 13Ghz, ETSI TR266, 3A 12,863 12,926 63 56
HP1-13-0266-3B ODU, HP 13Ghz, ETSI TR266, 3B 13,129 13,192 63 56
HP1-13-0266-4A ODU, HP 13Ghz, ETSI TR266, 4A 12,919 12,982 63 56
HP1-13-0266-4B ODU, HP 13Ghz, ETSI TR266, 4B 13,185 13,248 63 56
HP ODUs, – 15 GHZ
HP2-15-0315-1A ODU, HP2 15Ghz, ETSI TR315, 1A 14,627 14,732 105 56
HP2-15-0315-1B ODU, HP2 15Ghz, ETSI TR315, 1B 14,942 15,047 105 56
HP2-15-0315-2A ODU, HP2 15Ghz, ETSI TR315, 2A 14,725 14,844 119 56
HP2-15-0315-2B ODU, HP2 15Ghz, ETSI TR315, 2B 15,040 15,159 119 56
HP2-15-0315-3A ODU, HP2 15Ghz, ETSI TR315, 3A 14,823 14,928 105 56
HP2-15-0315-3B ODU, HP2 15Ghz, ETSI TR315, 3B 15,138 15,243 105 56
HP1-15-0315-1A ODU, HP 15Ghz, ETSI TR315, 1A 14,627 14,746 119 56
HP1-15-0315-1B ODU, HP 15Ghz, ETSI TR315, 1B 14,942 15,061 119 56
HP1-15-0315-2A ODU, HP 15Ghz, ETSI TR315, 2A 14,725 14,844 119 56
HP1-15-0315-2B ODU, HP 15Ghz, ETSI TR315, 2B 15,040 15,159 119 56
HP1-15-0315-3A ODU, HP 15Ghz, ETSI TR315, 3A 14,823 14,942 119 56
HP1-15-0315-3B ODU, HP 15Ghz, ETSI TR315, 3B 15,138 15,257 119 56
HP2-15-0420-4A ODU, HP2 15Ghz, ETSI TR420, 4A 14,501 14,613 112 56
HP2-15-0420-4B ODU, HP2 15Ghz, ETSI TR420, 4B 14,921 15,033 112 56
HP2-15-0420-5A ODU, HP2 15Ghz, ETSI TR420, 5A 14,606 14,725 119 56
HP2-15-0420-5B ODU, HP2 15Ghz, ETSI TR420, 5B 15,026 15,145 119 56
HP2-15-0420-6A ODU, HP2 15Ghz, ETSI TR420, 6A 14,718 14,837 119 56
HP2-15-0420-6B ODU, HP2 15Ghz, ETSI TR420, 6B 15,138 15,257 119 56
HP2-15-0420-7A ODU, HP2 15Ghz, ETSI TR420, 7A 14,816 14,928 112 56
HP2-15-0420-7B ODU, HP2 15Ghz, ETSI TR420, 7B 15,236 15,348 112 56
HP1-15-0420-4A ODU, HP 15Ghz, ETSI TR420, 4A 14,501 14,613 112 56
HP1-15-0420-4B ODU, HP 15Ghz, ETSI TR420, 4B 14,921 15,033 112 56
HP1-15-0420-5A ODU, HP 15Ghz, ETSI TR420, 5A 14,606 14,725 119 56
HP1-15-0420-5B ODU, HP 15Ghz, ETSI TR420, 5B 15,026 15,145 119 56
HP1-15-0420-6A ODU, HP 15Ghz, ETSI TR420, 6A 14,718 14,837 119 56
HP1-15-0420-6B ODU, HP 15Ghz, ETSI TR420, 6B 15,138 15,257 119 56
HP1-15-0420-7A ODU, HP 15Ghz, ETSI TR420, 7A 14,816 14,928 112 56
HP1-15-0420-7B ODU, HP 15Ghz, ETSI TR420, 7B 15,236 15,348 112 56
