Trango Systems, Inc. GigaPlus User Manual Rev 3.1 239
Outdoor Unit
Part Numbers
Description
TX Freq
Min*
(MHz)
TX Freq
Max*
(MHz)
Diplexer
Range
(MHz)
Max
Chan
Size
(MHz)
HP ODUs, – 23 GHZ
HP2-23-1008-1A ODU, HP2 23Ghz, ETSI TR1008, 1A 22,000 22,314 314 56
HP2-23-1008-1B ODU, HP2 23Ghz, ETSI TR1008, 1B 23,008 23,322 314 56
HP2-23-1008-2A ODU, HP2 23Ghz, ETSI TR1008, 2A 22,286 22,600 314 56
HP2-23-1008-2B ODU, HP2 23Ghz, ETSI TR1008, 2B 23,294 23,608 314 56
HP1-23-1008-1A ODU, HP 23Ghz, ETSI TR1008, 1A 21,994 22,330 336 56
HP1-23-1008-1B ODU, HP 23Ghz, ETSI TR1008, 1B 23,002 23,338 336 56
HP1-23-1008-2A ODU, HP 23Ghz, ETSI TR1008, 2A 22,274 22,610 336 56
HP1-23-1008-2B ODU, HP 23Ghz, ETSI TR1008, 2B 23,282 23,618 336 56
HP2-23-1200-5A ODU, HP2 23Ghz, ANSI TR1200, 5A 21,200 21,600 400 56
HP2-23-1200-5B ODU, HP2 23Ghz, ANSI TR1200, 5B 22,400 22,800 400 56
HP2-23-1200-6A ODU, HP2 23Ghz, ANSI TR1200, 6A 21,600 22,000 400 56
HP2-23-1200-6B ODU, HP2 23Ghz, ANSI TR1200, 6B 22,800 23,200 400 56
HP2-23-1200-7A ODU, HP2 23Ghz, ANSI TR1200, 7A 22,000 22,400 400 56
HP2-23-1200-7B ODU, HP2 23Ghz, ANSI TR1200, 7B 23,200 23,600 400 56
HP1-23-1200-5A ODU, HP 23Ghz, ANSI TR1200, 5A 21,200 21,600 400 56
HP1-23-1200-5B ODU, HP 23Ghz, ANSI TR1200, 5B 22,400 22,800 400 56
HP1-23-1200-6A ODU, HP 23Ghz, ANSI TR1200, 6A 21,600 22,000 400 56
HP1-23-1200-6B ODU, HP 23Ghz, ANSI TR1200, 6B 22,800 23,200 400 56
HP1-23-1200-7A ODU, HP 23Ghz, ANSI TR1200, 7A 22,000 22,400 400 56
HP1-23-1200-7B ODU, HP 23Ghz, ANSI TR1200, 7B 23,200 23,600 400 56
HP2-23-1232-1A ODU, HP2 23Ghz, ETSI TR1232, 1A 21,200 21,500 300 56
HP2-23-1232-1B ODU, HP2 23Ghz, ETSI TR1232, 1B 22,432 22,732 300 56
HP2-23-1232-2A ODU, HP2 23Ghz, ETSI TR1232, 2A 21,472 21,786 314 56
HP2-23-1232-2B ODU, HP2 23Ghz, ETSI TR1232, 2B 22,704 23,018 314 56
HP2-23-1232-3A ODU, HP2 23Ghz, ETSI TR1232, 3A 21,779 22,093 314 56
HP2-23-1232-3B ODU, HP2 23Ghz, ETSI TR1232, 3B 23,011 23,325 314 56
HP2-23-1232-4A ODU, HP2 23Ghz, ETSI TR1232, 4A 22,086 22,386 300 56
HP2-23-1232-4B ODU, HP2 23Ghz, ETSI TR1232, 4B 23,318 23,618 300 56
HP1-23-1232-1A ODU, HP 23Ghz, ETSI TR1232, 1A 21,200 21,500 300 56
HP1-23-1232-1B ODU, HP 23Ghz, ETSI TR1232, 1B 22,432 22,732 300 56
HP1-23-1232-2A ODU, HP 23Ghz, ETSI TR1232, 2A 21,472 21,786 314 56
HP1-23-1232-2B ODU, HP 23Ghz, ETSI TR1232, 2B 22,704 23,018 314 56
HP1-23-1232-3A ODU, HP 23Ghz, ETSI TR1232, 3A 21,779 22,093 314 56
HP1-23-1232-3B ODU, HP 23Ghz, ETSI TR1232, 3B 23,011 23,325 314 56
HP1-23-1232-4A ODU, HP 23Ghz, ETSI TR1232, 4A 22,086 22,386 300 56
HP1-23-1232-4B ODU, HP 23Ghz, ETSI TR1232, 4B 23,318 23,618 300 56
