Trango Systems, Inc. GigaPlus User Manual Rev 3.1 240
Outdoor Unit
Part Numbers
Description
TX Freq
Min*
(MHz)
TX Freq
Max*
(MHz)
Diplexer
Range
(MHz)
Max
Chan
Size
(MHz)
HP ODUs, – 26 GHZ
HP2-26-0800-1A ODU, HP2 26Ghz, ETSI TR800, 1A 24,250 24,450 200 56
HP2-26-0800-1B ODU, HP2 26Ghz, ETSI TR800, 1B 25,050 25,250 200 56
HP-26-0800-1A ODU, HP 26Ghz, ETSI TR800, 1A 24,250 24,450 200 56
HP-26-0800-1B ODU, HP 26Ghz, ETSI TR800, 1B 25,050 25,250 200 56
HP2-26-1008-1A ODU, HP2 26Ghz, ETSI TR1008, 1A 24,549 24,871 322 56
HP2-26-1008-1B ODU, HP2 26Ghz, ETSI TR1008, 1B 25,557 25,879 322 56
HP2-26-1008-2A ODU, HP2 26Ghz, ETSI TR1008, 2A 24,843 25,151 308 56
HP2-26-1008-2B ODU, HP2 26Ghz, ETSI TR1008, 2B 25,851 26,159 308 56
HP2-26-1008-3A ODU, HP2 26Ghz, ETSI TR1008, 3A 25,123 25,445 322 56
HP2-26-1008-3B ODU, HP2 26Ghz, ETSI TR1008, 3B 26,131 26,453 322 56
HP-26-1008-1A ODU, HP 26Ghz, ETSI TR1008, 1A 24,549 24,885 336 56
HP-26-1008-1B ODU, HP 26Ghz, ETSI TR1008, 1B 25,557 25,893 336 56
HP-26-1008-2A ODU, HP 26Ghz, ETSI TR1008, 2A 24,829 25,165 336 56
HP-26-1008-2B ODU, HP 26Ghz, ETSI TR1008, 2B 25,837 26,173 336 56
HP-26-1008-3A ODU, HP 26Ghz, ETSI TR1008, 3A 25,109 25,445 336 56
HP-26-1008-3B ODU, HP 26Ghz, ETSI TR1008, 3B 26,117 26,453 336 56
HP ODUs, – 28 GHZ
HP-28-1008-1A ODU, HP 28Ghz, ETSI TR1008, 1A 27,520 28,025 505 56
HP-28-1008-1B ODU, HP 28Ghz, ETSI TR1008, 1B 28,528 29,033 505 56
HP-28-1008-2A ODU, HP 28Ghz, ETSI TR1008, 2A 27,968 28,473 505 56
HP-28-1008-2B ODU, HP 28Ghz, ETSI TR1008, 2B 28,976 29,481 505 56
HP2-28-1008-1A ODU, HP 28Ghz, ETSI TR1008, 1A 27,520 28,025 1008 56
HP2-28-1008-1B ODU, HP 28Ghz, ETSI TR1008, 1B 28,528 29,033 1008 56
HP2-28-1008-2A ODU, HP 28Ghz, ETSI TR1008, 2A 27,968 28,473 1008 56
HP2-28-1008-2B ODU, HP 28Ghz, ETSI TR1008, 2B 28,976 29,481 1008 56
HP2-28-450-1A ODU, HP 28Ghz, ANSI TR450 1A 27,500 27,680 450 56
HP2-28-450-1B ODU, HP 28Ghz, ANSI TR450 1B 27,950 28,130 450 56
HP2-28-450-2A ODU, HP 28Ghz, ANSI TR450 2A 27,610 27,790 450 56
HP2-28-450-2B ODU, HP 28Ghz, ANSI TR450 2B 28,060 28,240 450 56
HP2-28-450-3A ODU, HP 28Ghz, ANSI TR450 3A 27,720 27,900 450 56
HP2-28-450-3B ODU, HP 28Ghz, ANSI TR450 3B 28,170 28,350 450 56
HP ODUs, – 32 GHZ
HP-32-0812-1A ODU, HP 32Ghz, ETSI TR812, 1A 31,815 32,207 392 56
HP-32-0812-1B ODU, HP 32Ghz, ETSI TR812, 1B 32,627 33,019 392 56
HP-32-0812-2A ODU, HP 32Ghz, ETSI TR812, 2A 32,179 32,571 392 56
HP-32-0812-2B ODU, HP 32Ghz, ETSI TR812, 2B 32,991 33,383 392 56
HP ODUs – 38 GHZ
HP1-38-0700-1A ODU, HP 38Ghz, ANSI/ETSI TR700, 1A 38,595 38,805 210 56
HP1-38-0700-1B ODU, HP 38Ghz, ANSI/ETSI TR700, 1B 39,295 39,505 210 56
HP1-38-0700-2A ODU, HP 38Ghz, ANSI/ETSI TR700, 2A 38,795 39,005 210 56
HP1-38-0700-2B ODU, HP 38Ghz, ANSI/ETSI TR700, 2B 39,495 39,705 210 56
HP1-38-0700-3A ODU, HP 38Ghz, ANSI/ETSI TR700, 3A 38,995 39,205 210 56
HP1-38-0700-3B ODU, HP 38Ghz, ANSI/ETSI TR700, 3B 39,695 39,905 210 56
HP1-38-0700-4A ODU, HP 38Ghz, ANSI/ETSI TR700, 4A 39,195 39,405 210 56
HP1-38-0700-4B ODU, HP 38Ghz, ANSI/ETSI TR700, 4B 39,895 40,105 210 56
HP2-38-1260-1A ODU, HP2 38Ghz ETSI TR1260, 1A 37,044 37,632 588 56
HP2-38-1260-1B ODU, HP2 38Ghz ETSI TR1260, 1B 38,304 38,892 588 56
HP2-38-1260-2A ODU, HP2 38Ghz ETSI TR1260, 2A 37,604 38,192 588 56
HP2-38-1260-2B ODU, HP2 38Ghz ETSI TR1260, 2B 38,864 39,452 588 56
HP1-38-1260-1A ODU, HP 38Ghz, ANSI/ETSI TR1260, 1A 37,044 37,632 588 56
HP1-38-1260-1B ODU, HP 38Ghz, ANSI/ETSI TR1260, 1B 38,304 38,892 588 56
HP1-38-1260-2A ODU, HP 38Ghz, ANSI/ETSI TR1260, 2A 37,604 38,192 588 56
HP1-38-1260-2B ODU, HP 38Ghz, ANSI/ETSI TR1260, 2B 38,864 39,452 588 56
* Frequencies shown are NOT center frequencies, but rather the edge of the transmit band.
Center frequency limits are 1/2 the channel bandwidth away from these numbers.
