\lf
LF (line feed)
$03.21,75.83,03.34,03.15,22.37,12.2,23.5,20.0,32<cr><lf>
5.10.2.4 WMT700 Data Message 24
WMT700 Data Message 24 reports wind measurement and self-diagnostics data. The
checksum is included in the message. WMT700 calculates the checksum by applying 8‑bit
XOR for all bytes between checksum calculation start point and end point. The result is
printed as a 2‑digit hexadecimal value.
\ss$\ws,\wd,\wp,\wm,\Ts,\vh,\vi,\ta,\er,\se\sp\cr\lf
\ss
Checksum calculation start point, not shown in the message
$
Fixed text
\ws
Wind speed, average
\wd
Wind direction, average
\wp
Wind speed, maximum
\wm
Wind speed, minimum
\Ts
Sonic temperature
\vh
Heater voltage
\vi
Supply voltage
\ta
Transducer temperature
\er
Status code. The code is a decimal number. Each bit corresponds to a status flag.
\se
Checksum calculation end point, not shown in the message
\sp
Print checksum (to verify message integrity)
Example of WMT700 Data Message 24
$03.45,76.03,03.58,03.37,21.97,23.8,23.6,23.8,0,0B<cr><lf>
Interpretation :
• Wind speed, average: 3.45 m/s
• Wind direction, average: 76.03°
• Wind speed, maximum: 3.58 m/s
• Wind speed, minimum: 3.37 m/s
• Sonic temperature: 21.97 °C
WMT700 User Guide M211095EN-H
122
